PRODUCT NAME
Joints for Flexible Pipe's Connection
Materials: UL approved Nylon PA66(Flammability UL 94V-2).
Working temperature: -40℃ to 100℃
Features: Product design is novel and unique, internal and external thread screw, quick connector type, used for Flexible Pipe's Connection, installation saves time and effort! The product can widely applied to resist water as a tough cable protection system for any machines, electric power equipment, engineering installation with the very specific demands.
| Item.No. | Adapt to Corrugated pipe | Adapt to Corrugated pipe |
|---|---|---|
| AD13.0-AD13.0 | AD13.0 | AD13.0 |
| AD15.8-AD15.8 | AD15.8 | AD15.8 |
| AD18.5-AD18.5 | AD18.5 | AD18.5 |
| AD21.2-AD21.2 | AD21.2 | AD21.2 |
| AD25.0-AD25.0 | AD25.0 | AD25.0 |
| AD28.5-AD28.5 | AD28.5 | AD28.5 |
| AD34.5-AD34.5 | AD34.5 | AD34.5 |
| AD42.5-AD42.5 | AD42.5 | AD42.5 |
| AD54.5-AD54.5 | AD54.5 | AD54.5 |
| AD15.8-AD13.0 | AD15.8 | AD13.0 |
| AD18.5-AD15.8 | AD18.5 | AD15.8 |
| AD21.2-AD18.5 | AD21.2 | AD18.5 |
| AD25.0-AD21.2 | AD25.0 | AD21.2 |
| AD28.5-AD21.2 | AD28.5 | AD21.2 |
| AD34.5-AD28.5 | AD34.5 | AD28.5 |
| AD42.5-AD34.5 | AD42.5 | AD34.5 |
| AD54.5-AD42.5 | AD54.5 | AD42.5 |
